| Dimensions (dXL) mm | |||||
|---|---|---|---|---|---|
| 3.0 X 13 | 3.5 X 16 | 4.0 X 16 | 4.5 X 20 | 5.0 X 25 | |
| 3.0 X 16 | 3.5 X 19 | 4.0 X 19 | 4.5 X 25 | 5.0 X 30 | |
| 3.0 X 19 | 3.5 X 25 | 4.0 X 25 | 4.5 X 30 | 5.0 X 35 | |
| 3.0 X 25 | 3.9 X 30 | 4.0 X 30 | 4.5 X 35 | 5.0 X 40 | |
| 3.0 X 30 | 3.5 X 35 | 4.0 X 35 | 4.5 X 40 | 5.0 X 45 | |
| 3.5 X 40 | 4.0 X 40 | 4.5 X 45 | 5.0 X 50 | ||
| 4.0 X 45 | 4.5 X 50 | 5.0 X 55 | |||
| 4.0 X 50 | 4.5 X 55 | 5.0 X 60 | |||
| 4.5 X 60 | 5.0 X 65 | ||||
| 3.0 mm | 3.5 mm | 4.0 mm | 4.5 mm | 5.0 mm | ||
|---|---|---|---|---|---|---|
| Torsional Strength (Nm) |
1.5 min | 2.0 min | 3.0 min | 4.3 min | 6.2 min | |
| Case Hardness (Hv/0.3kg) |
500-700 | 500-700 | 500-700 | 500-700 | 500-700 |
Installation diagram
‧ Suitable for chipboard.
